Stainless Steel Double Block and Bleed Valve
Check Stainless Steel Double Block and Instrumentation Bleed Valve Price List ex Mumbai
The Double Block And Bleed Valve is a kind of hydraulic manifold. The Double Isolation And Bleed Valve is known to replace the existing conventionally used methods, which were employed by pipeline engineers. Typically a Double Block And Bleed Gate Valve is used as a unit or manifold. Hence, the Double Block Bleed Valve is to be installed for positive isolation. Used for critical process service, Double Block And Bleed Plug Valve are designed for high pressure systems or the Double Block And Bleed Ball Valve can be used for toxic or hazardous fluid processes.
Applications that use Integral Double Block And Bleed Valve include chemical injection connection, instrument drain, chemical seal isolation, as well as gauge isolation. The corrosion resistant material Stainless Steel Double Block And Bleed Valve perform the work of three separate valves, i.e. 2 isolations and 1 drain. These valves require less space and are often light in weight. Similar to other fittings, the alloy used in the manufacture of the Dbb Valve will be based on the application. Check the latest Double Block And Bleed Valve Price List.
Manufacturer of SS 304 / 316 Integral Double Block and Bleed Ball/ Plug/ Gate/ Butterfly and Needle Valves in India
Os-Lok is your superior alternative to Swagelok & Parker A-lok. Similar to Parker, Os-Lok Stainless Steel Double Block and Bleed Valve are 100% leak free & used for oil, water, air, and inert gas.
SS Integral Double Block And Bleed Valve sizes
- Size: 1/2" to 4" (DN25-DN200)
- Thread: NPT PT BSPP G
- Connection : Welded, Socket, Clamped, Flanged, Threaded
- Pressure Class: PN10/ 16
Double Block And Bleed Valve Price List
- 1/8" Bleed Valve NPT 17.3 125 psi -20 Degrees to 160 Degrees F
Price $18.85 / each - Hydraulic InstrumentStainless Steel Monoflange Double Block and Bleed Valve
$5.00-$30.00 - DBB Series Stainless Steel Double Block and Bleed Valve
$10.00-$30.00 - Stainless Steel Double block and bleed valve rtj
$30.00-$55.00
Stainless Steel Block And Bleed Valve Specification
| Media | Oil, Gas & Water |
| Temperature of Media | Medium Temperature |
| Operation Way | Manual, Electric actuator, Pneumatic |
| Standard | 3A/ ISO/ DIN/ SMS / ASTM / JIS |
| Brand Name | OS-LOK |
| Packaging Details | PVC package, wooden case or as per customer's requirement. |
| Leakage rate |
|
| Working pressure | 3000 psig (206 bar) |
| Seal ring material | PPL, PTFE, PPL Soft Graphite |
| Manufacturing Process | Forged bar stock |
| OEM service | Yes |
| Connection |
|
| Thread Type |
|
| Function |
|
| Flow Rate | .93, 2.34, 6.42, .70, 1.04, 3.62,.87 Cv |
| Applicable Standard |
|
|
Approvals |
|
| We also stock & supply |
|
| Uses & application |
|
| Our representatives |
We have our sales representatives in folowing locations:
|
| Port | Mumbai, India |
Types of SS DBB Valve
- Stainless Steel Monoflange Hydraulic Instrument Double Block and Bleed Valve
- DBB Series Stainless Steel Double Block and Bleed Valve
- Stainless Steel 316 Double block and bleed valve rtj flange valve
- 1/2" NPT 6000 PSI Stainless Steel Double Block and Bleed Valve Hard Seat Needle Valves
- Stainless Steel Double Block and Bleed Valves Monoflange Valve (Class 150 to 2500 Flange)
- High pressure 3000PSI stainless steel swagelok type 3 way ball valve
- Auron Double Block Bleed Valve/ Auto Block Valve and rectangular Bellows
- 6000PSI Stainless Steel Block and Bleed Gas Valve/ DBB Valve
- Stainless steel double block and bleed valve for flange to NPT connection
- 2 way stainless steel 316 valve manifolds, single block and bleed valve
- Manual Stainless Steel 304 Block And Bleed Ball Valve
- SS Block and Bleed Needle Valve With Double Handles
- Stainless steel High quality Swagelok type Large-bore Bolted Double Block and Bleed Valves
- OS-LOK Stainless steel monoflange Double Block Bleed Valve
- High Temperature stainless steel double block and bleed valve
- High pressure SS DBB Double Block and Bleed Gate Valve
- High pressure 3000PSI stainless steel swagelok type 3 way ball valve
- One Piece Body 316SS Double Block & Bleed Valve API 6D
Stainless Steel Double Block and Bleed Valve grades
| GRADE / ALLOY | UNS Designation | FORGING | CASTING | BARSTOCK |
|---|---|---|---|---|
| 304 | S30400 | A182 F304 | A351 CF8 | A276 or A479 304 |
| 304L | S30403 | A182 F304L | A351 CF3 | A276 or A479 304L |
| 316 | S31600 | A182 F316 | A351 CF8M | A276 or A479 316 |
| 316L | S31603 | A182 F316L | A351 CF3M | A276 or A479 316L |
| 317L | S31703 | A182 F317L | A351 CG8M | A276 or A479 317L |
| 321 | S32100 | A182 F321 | - | A276 or A479 321 |
| 347 | S34700 | A182 F347 | A351 CF8C | A276 or A479 347 |
| 17-4PH | S17400 | A564 630 | - | - |
| 22% Duplex Stainless Steel | S31803 | A182 F51 | A890 Gr 4A | A276 or A479 S31803 |
| 25% Duplex | S32750 or 32760 | A182 F53 | A890 Gr 6A | A276 or A479 S32750 or 60 |
| 254SMO | S31254 | A182 F44 | A351 CK3MCuN | A182 F44 |
| 904L | N08904 | B625 N08904 | - | B649 N08904 |
